Now you can save the File and upload it to your sandwich.Īnother Example: LCD Board and 5-Band Board (This time with an older Software Version. Let´s say, our PA needs a PTT Signal, that is active LOW, then you need to remove // in front of #define NTX: If you want to Control PTT of an external PA, you additionally need to acticate one of the 2 Lines (depending of what your PA needs):Īn the End of the Block // QCX pin defintions: (Line Numbers vary over Time) This would be basically it, but there´s one hidden feature: The PA Output. Here´s my standard Setup for this: (changed lines marked).Additional choices up to you (Do you want CW Keyer ? or streaming over CAT, Do you want to have CW QRP Frequncies by defalut when changing Bad ? etc).Enable Rev 3 Relay Switching (= 8 Band Board).Disable Rev 2 Relay Switching (= 5 Band Board).This helps you with potential troubleshooting. -> If you´re running your sandwich 1st time, I´d suggest to leave DIAG on and disable CAT.Disable DIAG (not enough space together with OLED AND CAT).Let´s assume, we have and OLED IO Board and 8-Band RF Board. Made easily accessible for you.Īnything with “//” in front of the line is disabled (greyed out) and anything without those 2 slashes in front, is active. Those first lines of code are most of the available adjustment options. After opening the INO File (with Arduino Studio) from your (QCX SSB) Download, you should see the following situation:
There need to be some very minor changes in code in order to match your Hardware Setup. For programming the Software into the uSDX you need also Arduino Studio Software and a cheap Arduino UNO Board (or compatible) Then you have a (compressed) copy of the most recent GitHub Content on your Hard Disk.
#ONE MAN BAND SETUP DOWNLOAD ZIP#
The RX Improved Branch is a) way better in Performance then current Release Version “j” and b) the only Version, that supports Relay switching at this time.Ĭlick on the green “Code” Button and select: Download Zip Go to Guido´s GitHub Page (into Branch -> Feature RX Improved)
#ONE MAN BAND SETUP HOW TO#
Instead I´m showing you where to download the latest Version and how to adjust it for work with your Sandwich. It would not make sense to keep Software up to date on this Page.
